#50 Roller Chain x 3Foot + 2 Connecting Links

#50 Roller Chain X 3 Feet�
Ansi Chain No.: #50�
Length: 3 Feet
Width : 5/8"

Pitch (P): 0.625 inch (15.875 Mm)�
Roller Diameter (D1 Max): 0.4 inch (10.16 Mm)�
Width Between Inner Plates (B1 Min): 0.370 inch (9.4 Mm)�
Pin Diameter (D2 Max): 0.2 inch (5.08 Mm)�
Pin Length (L Max): 0.815 inch (20.70 Mm)�
Pin Length (Lc Max): 0.874 inch (22.20 Mm)�
Inner Plate Depth (H2 Max): 0.594 inch (15.09 Mm)�
Plate Thickness (T Max): 0.080 inch (2.03 Mm)�

Fits Aftermarket: 250-043, 250-127, 250-184, Trc50-Ts, 167-010,389,� 269250,� 167-010,� C5010,� L2305, 97507, 122010,� Sb-389,� 32-114,Rpc-50,� B1Sb389,� 283-0150,� 6706413

PP50_3
